M20L
The Mooney M20L is a long-body, single-engine piston aircraft with retractable landing gear, known for its unique Porsche PFM 3200 engine and single-lever power control. Key specifications include a 4-seat capacity, a maximum takeoff weight of around 2,900–3,368 lbs, and performance numbers such as a max speed of approximately 174 knots, a cruise speed of 155 knots, and a service ceiling of 25,000 ft.
You can watch this video to learn more about the Mooney M20, which includes information about the M20L PFM:
[
54s
Big Metal Birds
YouTube · Feb 9, 2024](https://www.youtube.com/watch?v=QT7CzszkMEY&t=634)
| Specification | Details |
|---|---|
| Manufacturer | Mooney |
| Model | M20L (PFM) |
| Engine | Porsche PFM 3200 N03 |
| Horsepower | 217 hp (approx.) |
| Seating | 1 pilot, 3 passengers |
| Max Takeoff Weight | 2,900 lbs (approx.) to 3,368 lbs |
| Max Speed | 174 kts to 161 kn (298 km/h) |
| Cruise Speed | 155 kts |
| Service Ceiling | 25,000 ft |
| Max Range | 1,445 nm |
| Fuel Capacity | 60 gal to 61 gal |
| Wing Span | 36 ft 5 in |
| Length | 26 ft 9 in |
