The man who loved circles (Objectivity):
More links & stuff in full description below ↓↓↓ Pappus chains, circle inversion and a whole lot more in this EPIC video with Simon Pampena. Support us on Patreon: http://www.patreon.com/numberphileNUMBERPHILE Website: http://www.numberphile.com/Numberphile on Facebook: http://www.facebook.com/numberphileNumberphile tweets: https://twitter.com/numberphileSubscribe: http://bit.ly/Numberphile_SubNumberphile is supported by the Mathematical Sciences Research Institute (MSRI): http://bit.ly/MSRINumberphileVideos by Brady Haran Brady's videos subreddit: http://www.reddit.com/r/BradyHaran/Brady's latest videos across all channels: http://www.bradyharanblog.com/Sign up for (occasional) emails: http://eepurl.com/YdjL9Numberphile T-Shirts: teespring.com/stores/numberphileOther merchandise: https://store.dftba.com/collections/n...
00:00
amazing you'll never be able to look at
00:02
circles the same way after I show you
00:04
the way to work out the radius of this
00:07
circle I've got something special for
00:10
you today I have a sequence of numbers
00:14
that I want you to be able to work out
00:17
what the next number in the sequence is
00:19
these are fractions so it's going to be
00:21
one on 15 one on 23 one on 39 one on 63
00:31
and then something there are lots of
00:37
ways I could show you how to solve this
00:38
but today I'm going to show you a very
00:41
special way how to solve it okay so
00:43
we're just going to put this over here I
00:44
need to get some equipment okay I got to
00:47
start drawing some circles my goodness
00:50
me have you ever have you ever done a
00:52
video where it's like the paper itself
00:54
has to be precise now I can use my other
01:01
precision instrument here my second
01:04
circle circle number to look at that
01:08
okay so these ones are exactly the same
01:11
and they're half the diameter of the big
01:15
circle this is going to be fun once we
01:17
actually get there that was hard to get
01:20
these ones to kiss so they're now
01:23
kissing these are kissing circles so
01:25
mathematically we'd say that they're
01:27
touching tangentially though they're
01:31
kissing now oh okay Brady you know hard
01:37
it is to get four circles to kiss do you
01:40
know how hard that is you know I have to
01:42
I have to confess you I've done this a
01:44
few times this is the best time I've
01:46
done it this blue circle here just so
01:56
happens that the radius of this blue
02:00
circle here is one fifteenth of this big
02:04
circle it's 1:15 hang on
02:12
okay let me keep going so this is called
02:15
a papist chain what I'm doing here so
02:17
having one circle touching the inside of
02:20
another circle kissing and then having
02:23
circles fitting in and touching all one
02:25
another it's a big touch fest today so
02:28
these things have been around for a long
02:29
time okay so this one here touching
02:41
touching touching so this one here this
02:43
is this new blue circle this one happens
02:46
to be one twenty third of the original
02:49
radius one twenty third 115-120 third
02:54
this one's good look at that beautiful
03:05
it is very zen the next one here this
03:11
little guy happens to be one thirty
03:14
ninth of the original large circles
03:19
there you go I don't know how much more
03:22
of this compass I can use okay so this
03:27
guy here his radius is 160 third the
03:32
original radius of the big circle 163rd
03:38
and so what's the next one going to be
03:40
well let's draw it in shall we
03:44
this here this here now belongs to these
03:49
circles and so the question is what is
03:53
the radius of this circle in reference
03:57
to our first circle now there's plenty
04:00
of ways we could actually work that out
04:02
we could get busy with our rulers and
04:06
start drawing triangles and maybe start
04:09
getting angles and maybe start using
04:12
different kind of theorems and whatnot
04:13
to try and get there but there is one
04:15
way to solve this problem which is
04:19
absolutely amazing absolutely amazing
04:22
great
04:23
it is the way to solve this problem what
04:25
I'm going to show you is actually
04:27
amazingly hard core is a huge amount of
04:30
information dealing with this so what
04:33
you have to do is I'm going to try and
04:34
show you just what we need for this
04:35
problem and hopefully you can go and
04:37
have a look at all the other stuff in
04:39
your own time but this is something that
04:41
we just go to Brady F trust me I'm going
04:43
to show you exactly what we need for
04:44
this problem and no more but if your
04:48
imagination is fired up that's because
04:52
you're thinking that's good the way to
04:54
solve this problem is using a method
04:57
called circle inversion there's a quick
04:59
introduction I think most people have
05:03
seen a reflection of themselves correct
05:06
so if you think about that you've got
05:09
your eyeball here so here's your eyeball
05:11
so now you know how reflections work
05:14
right so what you see is the mirror
05:17
opposite but what actually is going on
05:18
is it's this distance here 22 we're
05:22
going to do this quite rough Brady if
05:24
that's all right okay we know how
05:26
mirrors work don't we so over this it's
05:27
the eyeball it's your eyeball looking
05:29
back at you right this is called a
05:31
reflection so we're going to do a
05:33
special type of reflection to solve this
05:35
problem it's called a circle inversion
05:37
okay now this is how it works first off
05:41
you got to start with a circle so this
05:44
circle here we're going to be it's our
05:46
circle of inversion so first of all what
05:48
we need to do is we need to what we need
05:50
to know the radius that's really
05:53
important Brady okay
05:56
so in this case here the radius is 60
06:00
say we put a point out here okay so say
06:06
we put a point here okay and that point
06:10
there is going to be a and this point
06:14
here is o 4 origin so now we did a
06:18
reflection what happens in inversion is
06:21
first of all we're going to measure oh a
06:24
so we know how a equals 30 so this point
06:30
here we're actually going to invert it
06:33
and this is how you do it
06:35
you take this length here right which we
06:40
know is 30 and you multiply by the point
06:44
we're going to we don't know where it is
06:46
just yet and it equals the circle radius
06:51
squared so this equals 60 squared so in
06:59
this case this is 30 times where we want
07:04
to go equals 60 squared so if we just
07:11
divide through and do a quick little bit
07:13
of calculation then that goes twice so
07:16
that means equals 120 and so what that
07:23
what we've done there is we've actually
07:27
taken this point all the way out on
07:30
exactly the same line to here so this
07:37
length here is Oh a dash and it equals
07:40
120 and this length here is okay
07:43
and that equals 30 so 30 times 120
07:47
equals the radius squared so this point
07:50
has been inverted to this point so
07:53
whether you're inside the circle you go
07:55
to the outside and if you're outside you
07:57
go to the inside and it's all based on
07:59
this these formulas so that's it that
08:03
circle inversion you want to see what
08:04
circle inversion can do in please right
08:06
so I've just drawn a circle within my
08:09
circle of inversion so we've only
08:11
inverted one point what happens to all
08:13
the points the infinite number of points
08:15
in a circle when you do the same process
08:17
okay so we're going to take that circle
08:20
and invert it we're going to invert the
08:22
circle that's right so what do you think
08:24
is going to happen to all these points
08:25
tell me well my instinct yeah is that
08:29
you draw another circle out out here
08:33
somewhere out in the in the great beyond
08:35
is going to be circular that would be my
08:38
instinct not an oval my instinct is will
08:41
be another circle G you've got good
08:42
instincts
08:45
so this point here has been inverted to
08:48
that point there so you can see the
08:50
closer it is to the circle of inversion
08:52
the closer it is on the other side so
08:55
cave divide that O'Brady so we haven't
09:00
planned this very well this is huge
09:02
so cos this one is here this inverts out
09:06
all the way to here so this has already
09:08
got some very unusual properties right
09:11
Wow look at this we've actually gone
09:13
over the original and we're all over the
09:15
place with this one this is huge so it's
09:18
different to a reflection where this
09:21
where it's not scaled but this in a
09:23
sense is scaled this inverts to this and
09:27
what you'll find is that you'll get
09:32
these points on the edge you see that
09:34
where they're both touching there'll be
09:36
one point where they touch both here and
09:38
here at one point where they touch over
09:40
here and here okay if we measure this
09:45
length and times it by that length
09:46
we'll get 60 squared okay so what
09:51
happens is a circle will invert to
09:54
another circle okay and we don't have to
09:58
do this because we showed before the
09:59
points go back so if we started with
10:01
this circle on the outside it had come
10:04
back to this one now the other thing
10:07
that you need to know is that this is
10:09
true as well if the circle happens to
10:12
overlap the circle of inversion so you
10:15
could think what happens if the circle
10:17
that we're inverting what happens to
10:20
this circle Brady well we still get a
10:22
circle well we will we definitely still
10:25
get a circle this point if this is a
10:27
little important of invert to a point
10:30
there is only a fraction in what yeah
10:33
exactly that's going to start there and
10:36
come out big yep but what's the two
10:38
points we've already seen on the circle
10:40
can you see two points that we already
10:42
know are going to be on this inverted
10:43
circle the ones that touch the line the
10:46
ones that intersect the line exactly so
10:51
you can you see there Brady we've done a
10:52
inversion circle and it's crossed here
10:56
it's crossed here kind of
10:58
a little bit there but you can see that
11:01
it still makes another circle now is one
11:04
more I'm going to show you is one more I
11:07
got to show you I can I just say it's
11:09
important that you prove these things to
11:10
yourself but I'm not going to prove them
11:12
today I'll show you this because this
11:14
one this one's weird and what about a
11:16
circle that actually passes through the
11:18
origin well think about it well if
11:21
there's a point on the origin right
11:24
what's the length from the origin if
11:26
you're at the origin zero so in really
11:32
it's going to blow up so points that get
11:35
very very close to the origin are going
11:36
to get huge towards infinity so we're
11:39
really talking about a massive circle
11:41
here and you know how massive it just
11:44
looks like a line so any circle that
11:47
passes through the origin of the circle
11:49
inversion will invert to a line and lo
11:53
and behold check it out look at that so
12:00
circle inversion amazing look at the
12:04
properties circles invert two circles
12:07
okay
12:08
big goes to small small goes to big if a
12:11
circle crosses the circle of inversion
12:13
it still looks like a circle and then I
12:16
think most stunning of all a circle that
12:18
passes through the origin will invert to
12:21
a straight line so this is all we need
12:23
these two facts will kind of fact 1a and
12:29
1b and then fact two okay that's all we
12:33
need so now with our information about
12:35
circle inversion how can we actually
12:37
solve this problem well what we need to
12:43
do first we need to make a decision
12:44
about what sort of circle we're actually
12:48
going to use to invert the way to solve
12:50
this is to get this bad boy again and
12:53
what we're going to do is we're actually
12:54
going to do a circle of inversion that
12:58
is exactly the same as our original
13:01
circle okay so this is our original
13:02
circle we're going to put the origin of
13:05
our circle of inversion right at the end
13:08
so this this green dotted line is our
13:11
Circle of inversion and this is what
13:14
we're going to do all our work with okay
13:17
so this is our circle of inversion and
13:19
remember it's got exactly the same
13:21
radius as our original circle that's
13:24
important now
13:26
remember what I said Brady what are the
13:28
what are the things that we need to know
13:30
about inversions we need to know circles
13:34
invert two circles if they go over the
13:38
same over the circle of inversion they
13:39
still in virtuous circles unless part of
13:43
the circle goes through the center of
13:45
origin of the circle of inversion then
13:47
it turns into straight wrong bingo now
13:52
this is the reason why I came because
13:54
now I am able to invert these circles
13:57
and just using a ruler right I'm able to
14:02
Mabel to show you how beautiful how
14:03
simple it is now to interpret this
14:05
problem this big circle here Brady this
14:08
big circle here what does it invert -
14:10
well first of all it passes through the
14:12
center of inversion so we know it coz is
14:14
going to turn into a straight line now
14:17
where is that straight line going to be
14:18
well you know what I don't have to
14:20
calculate anything because I already
14:22
know that it intersects the circle of
14:25
inversion there so this is the radius so
14:31
this point goes back to itself so we
14:35
know that this point is on the straight
14:37
line because it intersects the circle of
14:39
inversion I know what the other one is -
14:43
where exactly so straight away you only
14:49
need two points to the final line yeah
14:53
so that we we know we can actually just
14:57
really simply draw this in we've
15:04
just put a our first inverted circle
15:06
next what about this circle here so this
15:10
circle here also passes through the
15:12
center of origin but it kisses the
15:15
inside it kisses the inside of the
15:19
inversion circle now that means it's
15:21
going to invert to a straight line
15:24
exactly but where is it going to be is
15:27
it going to be a straight line like that
15:29
or like that well let's have a look this
15:34
circle here okay and this circle here
15:39
are both going to invert two straight
15:41
lines but they only touch at the point
15:45
of origin and that point of origin in
15:48
effect is infinity so if two lines only
15:54
touch at infinity well this is kind of
16:00
tricky stuff here that's parallel that's
16:02
the only that's the only explanation
16:03
really isn't it so you see the logic
16:06
that you can draw out of just these
16:07
simple rules of circles go to circles
16:09
the logic here is that well if it goes
16:12
anything else it will eventually hit
16:14
which means that point must be an
16:17
intersecting point back here but we know
16:19
that doesn't happen because there's
16:21
origin point so you can deductively
16:23
reason what happens here okay Brady so
16:29
this big circle is this one and this
16:32
circle is this one now what happens to
16:35
this circle here well again we don't
16:39
have to measure anything this circle
16:41
here touches the big circle and touches
16:44
this circle and we already know that
16:47
this circle is that line and this circle
16:49
is that line so this has to be touching
16:52
both this and this and so really there's
16:56
only one thing it can be if a circle
16:58
inverts to a circle it has to be a
17:01
circle that fits between these parallel
17:04
lines well let's draw that in Brady
17:11
this has happened to there this point
17:13
hasn't moved because it's on the circle
17:15
of inversion but a circle has inverted
17:18
to a circle now what about this guy here
17:21
how do we invert this one well straight
17:26
away we know that two points have to be
17:29
here and here because they invert well
17:33
they're on the circle of inversion
17:35
where's another point well this one here
17:38
is on this circle here and even though
17:41
it actually in in this diagram it
17:44
actually is on it an inverted circle we
17:46
have to remember that that's not where
17:47
it's going it's actually going to here
17:50
okay this guy here these two touch right
17:53
there so this is touching this circle
17:56
this circle of this circle I think you
17:59
should be able to see what's going on
18:00
now if this circle is touching this
18:02
circle this circle and this circle then
18:06
in the inversion these two circles
18:09
aligns this circle is here this has to
18:11
touch that that and that
18:14
which means it has to be another a
18:15
circle exactly the same radius exactly
18:18
the same diameter see how much symmetry
18:21
there is how beautiful this is how
18:23
awesome this is Brady I mean this the
18:26
symmetry of this is just breathtaking in
18:28
the inverted world we still get kissing
18:31
okay now Brady there's another circle
18:40
this blue one here this is the guy here
18:43
which is one fifteenth of the original
18:48
radius is what I told you now we
18:50
actually have to invert this guy so this
18:53
circle is that circle this circle is
18:55
that circle this circle is actually over
18:57
here so that circles there so this guy
19:01
in here is kissing one two three and of
19:04
these purples it's one two three so we
19:08
know that this blue guy has to actually
19:10
be in here has to touch all three so is
19:14
it a rule that if you kiss in real life
19:16
you have to kiss
19:17
exactly now this little circle is the
19:20
inversion of the blue circle what about
19:22
the one that we really want this one
19:24
down here how do we get there
19:26
well we've inverted one two we're going
19:30
to invert this guy now so this guy
19:32
inverts and you know what it's becoming
19:35
so simple to do because we know that
19:39
it's a circle that has to touch this guy
19:41
here so this is touching this and this
19:43
is this so this circle has to touch here
19:46
is touching the big circle which we know
19:48
is that line you know it's such in this
19:49
circle it's that line so it's just a
19:51
straightforward process
19:53
where we now have to just draw circles
19:55
in one on top of another
19:58
this Pappas chain of circles getting
20:01
progressively smaller and smaller and
20:03
smaller under inversion ends up being
20:05
circles stacked on top of each other
20:08
exactly the same radius exactly the same
20:11
diameter because they're fitting between
20:12
two parallel lines so this is absolutely
20:16
beautiful this is this one this is this
20:19
one this is this one this is this one
20:21
this is this one so now if we think
20:23
about it in the Pappas chain the blue
20:25
guys are touching these circles and
20:29
touching this circle here so in the
20:32
inversion okay we've already seen that
20:34
this blue circle inverts here so the
20:37
pattern is going to stay the same
20:39
there's going to be a circle there it's
20:41
going to be a circle there they're going
20:42
to circle the other than T so for their
20:43
circle bit and all going to be exactly
20:46
the same size okay so if we can work out
20:48
the diameter of this we can work out the
20:53
diameter of this and then we've got the
20:55
radius so how can we do that this is
20:59
epic this is seriously epic all right
21:04
here we go so we've got now this is a
21:11
right angle and we know that this circle
21:15
here even though that's so tiny the
21:19
center of this circle will pass through
21:23
the center of this circle up here
21:28
we now have a massive right angle
21:31
triangle if we know this length here we
21:35
can invert that length and it will give
21:37
us the length through this circle and
21:40
because it's passing through the origin
21:43
of this little circle it will tell us
21:46
the diameter and if we divide that by
21:48
two it will tell us the radius so shall
21:54
we do it let's bring this home I tell
21:56
you what this is absolutely epic
21:59
it's very pretty though this whole this
22:01
whole length here is our it's the circle
22:03
of inversion so this half here is going
22:05
to be our on to right and this length
22:09
here
22:10
well this circle here is a half of that
22:12
so right from here to here that's our
22:15
own four and this this little blue
22:17
inverted circle here is a quarter of
22:20
that there so that's actually our on 16
22:24
so just here so what we're going to do
22:27
is we know that this whole length here
22:29
all the way across our take our on 16
22:35
which is equal to 15 are on 16 so that's
22:42
what that length is equal to now what
22:45
about this long guy here well again here
22:50
this distance from here to here is going
22:53
to be at our own 4 and all of these are
22:59
on 2 are on 2 plus r2 plus r1 2 plus our
23:03
own - so that's going to be R plus R so
23:07
that's 2 R plus R on 4 so what we've got
23:12
here then so this whole length here
23:15
that's huge 9r on for now what we want
23:21
to do is that we've got Pythagoras's
23:23
theorem and we worked out this length
23:25
and this length we can work out the
23:26
hypotenuse from this o which is the
23:30
center of the circle inversion all the
23:32
way to this center here of this blue
23:34
circle when you work that out that comes
23:37
to 39 on
23:41
sixteen are now we actually want to know
23:47
the distance Oh to be dashed because we
23:52
know that will invert right back to this
23:54
small circle and we also want to know Oh
23:57
- OH - but let's do this one first so we
24:00
know that o to B dash is equal to 39 on
24:07
16 are plus the radius of the small
24:12
circle which is are on 16 so that equals
24:18
this Oh a so OAS over here we're going
24:24
back from this by our on 16 we're going
24:28
back by the radius so it looks like this
24:31
39 on 16 our take are on 16 same
24:36
denominators so 39 so we end up getting
24:39
38 on 16 are now we want to invert these
24:44
so we want to take o to be - back to be
24:48
okay so let's do that
24:50
so o to be when we invert this we end up
24:55
getting 16 on 40 ah okay
25:01
and we do the same thing with OH - a -
25:04
we bring it back to the tiny little
25:05
circle there and that means either the a
25:08
is this inverted okay and then we end up
25:13
getting 8 on 19 are now we've got out of
25:21
the a out of the B we know they passes
25:24
through the center so we know if we go
25:27
oh a take o be we will get the diameter
25:34
of this small circle and that happens to
25:39
make it 2 so that's that take that which
25:45
ends up being 2 on 95r
25:52
because the radius is half the diameter
25:55
so the radius here of this small circle
26:00
so radius of small circle equals one on
26:08
95r so we know that the original circle
26:15
if we divide by 95 will give us that
26:18
radius which means this is 1 1 95
